Printer Epson LX-310 | Printer Dot Matrix

Deskripsi Printer Epson LX-310

WHY THE EPSON LX-310?
Building on its reputation as the world’s top dot matrix printer maker, Epson has introduced the Epson LX-310 as the next-generation narrow carriage, 9-pin model that replaces the legendary LX-300, featuring vastly improved speed and reliability.

Extreme Speed
The Epson LX-310 features a 128KB input data buffer memory that is double that of its predecessor. This enables it to achieve high printing speeds of up to 357 characters per second at 12 CPI.

Improving on Legendary Reliability
The Epson LX-310 also has an improved reliability rating that is an astonishing 67% higher than its predecessor that was already renowned for its dependability. The LX-310 is rated for a mean time before failure (MTBF) of 10,000 POH (power on hours) compared to the older model’s 6,000 POH.

High Impact for Multiple Carbon Copies
Achieve optimum efficiency with the LX-310’s ability to create up to a 5-part form printout (1 original + 4 copies).

Flexible Connectivity
With built-in USB, Serial and Parallel Interface options, the LX-310 is able to connect to just about any output device you need it for.

Spec Printer EPSON LX-310:

MODEL NUMBER	LX-310
Printing Technology
Print Method	Impact dot matrix
Number of Pins in Head	9 pins
Print Direction	Bi-direction with logic seeking
Control Code	ESC/P and IBM PPDS emulation
Print Speed
High Speed Draft10/12/15 cpi	347 / 357 / 390 cps
High Speed Draft Condensed17/20 cpi	383 / 298 cps
Draft10/12/15 cpi	260 / 312 / 223 cps
Draft Condensed17/20 cpi	222 / 260 cps
Draft Emphasized10 cpi	130 cps
NLQ10/12/15/17/20 cpi	65 / 78 / 55 / 47 / 56 cps
Print Characteristics
Character Sets	Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15
Bitmap Fonts	Epson Draft: 10, 12, 15 cpi; Epson Roman & San Serif: 10, 12, 15 cpi, Proportional; Epson Courier: 10, 12, 15 cpi; Epson Prestige: 10, 12 cpi; Epson Script, OCR-B, Orator & Orator-S: 10cpi; Epson Script C: Proporational
Barcode Fonts	EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet
Printable Columns
Pitch10/12/15/17/20 cpi	80 / 96 / 120 / 137 / 160 cpl
Paper Handling
Paper Path
Tractor	Rear in, Top out
Manual Insertion	Rear in, Top out
Paper Size	LengthWidthThickness
Cut Sheet (Single Sheet)	100 – 364mm (3.9 – 14.3″)100 – 257mm (3.9 – 10.1″)0.065 – 0.14mm (0.0025 – 0.0055″)
Cut Sheet (Multi Part)	100 – 364mm (3.9 – 14.3″)100 – 257mm (3.9 – 10.1″)0.12 – 0.39mm (0.0047 – 0.015″) (Total)
Envelope (No.6)	92mm (3.6″)165mm (6.5″)0.16 – 0.52mm (0.0063 – 0.0205″) (Total)
Envelope (No.10)	105mm (4.1″)241mm (9.5″)0.16 – 0.52mm (0.0063 – 0.0205″) (Total)
Continuous Paper (Single Sheet an Multi part)	101.6 – 558.8mm (4.0 – 22.0″)101.6 – 254.0mm (4.0 – 10.0″)0.065 – 0.39mm (0.0025 – 0.015″) (Total)
Roll Paper	216mm (8.5″)0.07 – 0.09mm (0.0025 – 0.0035″)
Paper Feeding
Standard	Friction, Push Tractor
Optional	Roll Paper Holder
Copies	Original + 4 copies
Line Spacing	4.23mm (1/6″) or programmable in increments of 0.118mm (1/216″)
Input Data Buffer	128KB
Interface
Standard	Bi-directional parallel interface (IEEE-1284 nibble mode supported) USB 2.0 Full-Speed Serial
Ribbon Cartridge
Standard	Fabric Ribbon Cartridge (Black)
Ribbon Life	Approx. 4.0 million characters (Draft 10cpi, 14 dots/character)
Acoustic Noise	Approx. 53dB(A) (ISO 7779 pattern)
Reliability
Mean Print Volume Between Failure (MVBF)	Approx. 20 million lines (Except print head)
Mean Time Between Failure (MTBF)	Approx. 10,000 POH (25% Duty)
Print Head Life	Approx. 400 million strokes/wire
Control Panel	4 switches and 5 LEDs
Environmental Conditions (Operating)
Temperature	5 ~ 35°C
Humidty	10 ~ 80% RH
Electrical Specification
Rated Voltage	AC 120V / AC 220 – 240V
Rated Frequency	50Hz – 60Hz
Power Consumption
Operating	Approx. 27W (ISO/IEC 10561 Letter pattern),(ENERGY STAR compliant)
Sleep Mode	Approx. 1.1W
Auto Off Mode	Approx. 0.2W (120V), Approx. 0.3W (230V)
Power Off	0W
Printer Driver / Utility
Operating System	Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®
Utility
Epson Status Monitor 3	Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®
Epson Printer Setting	Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®
Dimensions and Weight
